FLIR 427-1064-41-00 FB-312 O - 18MM, 25HZ, EU
FLIR 427-1064-41-00 FB-312 O - 18MM, 25HZ, EU
Regular price
$2,054.43 USD
Regular price
$2,568.04 USD
Sale price
$2,054.43 USD
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The compact FLIR Elara™ FB-Series O thermal security camera delivers industry-leading thermal imaging for perimeter and wide area protection around the clock. The camera also offers "plug-and-play" compatibility with external video analytics and major VMS suppliers, including FLIR United VMS, for additional functionality and a flawless user experience.
General
- Detector Type
- Long-Life, Uncooled VOx Microbolometer
- Dimensions (L x W x H)
- 285 x 96 x 94 mm/11.1" x 3.8" x 3.7" With sunshield and fully extended mounting arm
- Effective Resolution
- 76,800 pixels
- Focus Range
- Athermalized, focus-free
- Input Voltage
- 12 VDC 24VAC PoE
- Power Consumption
- 12 VDC: 17 W (maximum with heaters) 24VAC : 13 VA (maximum with heaters) 24VDC : 13 W (maximum with heaters) PoE: 13 W
Environmental
- Humidity
- 10%-90% relative humidity
- IP Rating (dust & water ingress)
- IP66
- Operating Temperature Range
- -40°C to 50°C
- Regulatory
- FCC Part 15 (Subpart B, Class A), CE marked, EN55032, EN55024, RoHS, WEEE
- Storage Temperature Range
- -20°C to 70°C
System Integration
- Ethernet
- 10/100 Mbps
- External Analytics Compatible
- Yes
- Network APIs
- Nexus SDK for comprehensive system control and integration; Nexus CGI for http command interfaces; ONVIF Profile S
- Supported Protocols
- IPV4, HTTP, Bonjour, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP
Thermal Camera
- Image Uniformity Optimization
- Automatic Flat Field Correction (FFC) - Thermal and Temporal triggers
- Pixel Pitch
- 12u
- Thermal AGC Region of Interest [ROI]
- Default, Presets and User Defined for optimal image quality of subjects of interest
- Thermal Image Settings
- Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast
Video & Recording
- Composite Video NTSC or PAL
- Hybrid system with IP & analog video
- Digital Video Compression
- Two independent channels of H.264 and MJPEG
- Streaming Resolution PAL/NTSC
- Native: 320x256
Visible Camera
- Array format
- 320 × 240
- Field of view (FOV)
- 12°
- f-number
- F1.0
- Focal Length
- 18mm
- Sensitivity
- <50mK @ 25c F# 1.0
- Spectral Range
- 8 µm to 14 µm
- Video Frame Rate
- NTSC: 30 Hz PAL: 25 Hz
